Slings and anchor points: Safe lifting of loads
There is hardly any other field of connection technology where there is so much focus on the safety and reliability of the products as in load-handling equipment! With our high-quality slings and anchor points, we deliver the safety you need.
We offer you suitable screw-type or weld-on load handling attachments, rotatable or non-rotatable, in various strength classes for various anchoring procedures.
Whether it is a swivel hoist ring, hoist ring, anchoring bracket, welding hook, welding bracket, load ring, sling swivel, ring bolt according to DIN 580, eye nut, eye bolt, PPE ring bolts or safety spare parts, you will find the right fastener for safe lifting, turning or lashing of heavy loads in our online shop.
Slings. With certainty and certification.
Our product range offers you high-strength anchor points, which guarantee a 4-fold safety in all load directions and meet the high demands of the DGUV (German Social Accident Insurance) regulations in addition to the CE certification. These slings also meet the requirements of the Machinery Directive (2006/42/EC).
Würth is quality. After the manufacturing process, each part is inspected for minor cracks in order to eliminate defects and faults.
Ring bolts DIN 580 are the cheap classic. However, comparing the load capacity of a washer to other anchor points from our range shows that these ring bolts quickly reach their limits (e.g., with M10 thread).
| Load direction | Ring bolt DIN 580 | Ring bolt 8.8 | Ring bolt alignable 8.8 | Ring bolt alignable HQ |
|---|---|---|---|---|
| Load direction 0° | 230 kg | 1000 kg | 1000 kg | 1000 kg |
| Load direction 45° | 170 kg | 350 kg | 350 kg | 560 kg |
| Load direction 90° | 115 kg | No information | 500 kg | 800 kg |
Safe attachment of loads.
In addition to the selection of the correct sling in terms of its load capacity and proper storage, safe handling is of great importance in order to move heavy components or loads safely. Always select the sling based on its features, load capacity and strength class suitable for the respective application! In addition to this, always ensure that the sling is used as intended: you may only use the lifting gear in accordance with the permissible load direction and stop position. The lifting process must always be carried out carefully! Furthermore, you should always have your slings checked for wear and tear by qualified persons with advanced technical knowledge.
In our brochure about slings, you will find the technical specifications and associated application notes for our products.
Related topics about slings
Our in-house product series W.TEC® represents our carefully curated selection of products that stand out due to their excellent functionality and top class quality. Each product has been developed with the highest quality standards in order to meet the requirements of the industrial customers. This combination of precision and performance makes the products of our W.TEC® series price and performance champions.
Slings – Essential for plant engineering!
Lifting or moving components can be a big challenge in plant engineering. Especially when parts have to be mounted on structures or when motors and gear boxes have to be lifted, safe loading of large modules or parts is of utmost importance.
We know the specific requirements of companies in mechanical and plant engineering, especially in the supply of C-Parts! Our CPS®MACHINERY department takes care of the special requirements of this important industry.
